NOW IN STOCK: Panasonic LUMIX S5!
29 September 2020 | Category: General News
The 4th model of the LUMIX S Series is here. Packing the essence of the conventional S Series camera in a compact, lightweight body, this new hybrid full-frame mirrorless camera from Panasonic provides excellent performance in both shooting photos and recording videos for serious, enthusiastic photographers and videographers.
At the heart of the camera, the LUMIX S5 contains a 24.2-megapixel 35mm full-frame CMOS sensor that boasts wide dynamic range and high sensitivity performance. The LUMIX S5 further realises a maximum ISO 51200 of crystal-clear high sensitivity video with the adoption of the Dual Native ISO technology.
As a pioneer of hybrid mirrorless cameras, Panasonic LUMIX has the largest line-up of cameras that record 4K 10-bit video as of the second of September 2020. The latest member of the family, the LUMIX S5, is capable of 4K 60p/50p 4:2:0 10-bit, and 4K 30p/25p 4:2:2 10-bit internal recording. It is also capable of 4K 60p/50p 4:2:2 10-bit HDMI output. For 4K 30p/25p 4:2:0 8-bit internal recording, there is no time limitation as Panasonic’s exceptional heat dispersion technology enables stable and continuous video recording.
The LUMIX S5 provides 14+ stops of dynamic range, which is as wide as cinema cameras, and V-Log / V-Gamut compatibility with popular VariCam colour science. A variety of recording formats and modes including 4:3 anamorphic mode, slow & quick motion, 4K/60p interval shooting and 4K HDR are also provided.
The LUMIX S5 also possesses improved high-speed, high-precision AF in both photo shooting and video recording that has been made possible with advanced deep-learning technology featuring real-time detection of the subject such as human eye, face, head and body recognition.
Thanks to a new highly energy-efficient 2,200mAh high-capacity battery, the S5 can capture approximately 470 pictures using the LVF / 1,500 pictures in Power Save LVF mode. It complies with a USB power charging and power supply.
Double SD card slots (UHS-IIx1 and UHS-I x1), 5GHz/2.4GHz Wi-Fi and Bluetooth 4.2 connectivity are also supported. The splash/dust-resistant rugged design provides professionals with high reliability.
The LUMIX S Series full-frame mirrorless camera system adopts the L-Mount system to provide users with a diverse and future-proof range of products from Panasonic, Leica Camera and Sigma.
Exceptional video recording performance for cinema-quality film creation
The LUMIX S5 delivers class-leading video performance and is capable of 4K 60p/50p 4:2:0 10-bit, and 4K 30p/25p 4:2:2 10-bit internal recording up to 30 minutes. It is also capable of 4K 60p/50p 4:2:2 10-bit HDMI output. For 4K 30p/25p 4:2:0 8-bit internal recording, there is no time limit.
To further enhance its performance, a firmware update is scheduled for the LUMIX S5 by the end of 2020. In addition to C4K video recording, the update will support RAW video data output to ATOMOS NINJA V over HDMI at a resolution of 5.9K (5888x3312) 29.97p/25p, 4K(4128x2176) 59.94p/50p and anamorphic 3.5K (3536x2656)/50p. A variety of video recording assist functions such as the Vector Scope Display, Master Pedestal Adjustment and SS/Gain Operation(SEC/ISO, ANGLE/ISO, SEC/dB) will also be available. L.MonochromeS and L.ClassicNeo are the new options to be added for photo style.
The LUMIX S5 delivers 14+ stops of dynamic range, virtually the same as those of the Panasonic cinema cameras, to precisely reproduce everything from dark to bright areas. The ability to capture accurate colours and skin tones is a must for any filmmaker. The LUMIX S5 imports the renowned colour science of Panasonic’s VariCam line-up of cinema cameras, as well as V-Log / V-Gamut.
V-Log renders a very flat image whilst maintaining all of the colour information, meaning there is more room to play in post-production. The CMOS sensor of the LUMIX S5 achieves a wide colour gamut known as V-Gamut, which is the S5’s optimum colour space that is wider than BT.2020. V-Log has log curve characteristics that are reminiscent of negative film and V-Gamut delivers a colour space even larger than film. 35 conversion LUTs for VariCam cinema cameras can be downloaded free of charge for use in the LUMIX S5. It is easy to match the colour tone with the footage recorded in V-Log of S1H/S1 and V-Log L of GH5/GH5S. Practical tools like a waveform monitor and V-Log view assist are also available.
With Slow & Quick mode, impressive video slow and quick motion in 4K (1-60fps, 30x quick to 2.5x slow) or in FHD (1-180fps, 60x quick to 7.5x slow)*1 is available. It is possible to use AF*3 to capture the subject in sharp focus in this mode too. It can also be accessed directly using the mode dial.
The HDR (High Dynamic Range) video recording in 4K is also available, which realistically reproduces both light and dark parts of an image. The camera records video with a designated gamma curve compatible with ITU-R BT.2100, and the user can now choose Hybrid Log Gamma (HLG) in Photo Style. The HLG*2 Photo mode provides a wider dynamic range to reproduce light and shadow with more natural contrast. The HLG Photos can also be produced as an HSP file*3 with compressed high-brightness signals in its full resolution (5,888 x 3,312, in 16:9) in addition to JPEG/RAW files. The user can playback these vibrant images on the latest Panasonic HLG-compliant 4KTV via HDMI cable connection or other HLG-compliant devices.
In continuous burst shooting, 6K PHOTO*4 makes it possible to capture unmissable moments at 30 fps by extracting the frame with the best timing out of a 6K burst file (in 4:3 or 3:2 aspect ratio) to save as an approximate 18-megapixel equivalent high-resolution photo.
*1 The AF mode switches to MF when the frame rate is set to of 150 fps or more. The angle of view is reduced when the frame rate is set to 180 fps. Recording stops when the continuous recording time exceeds 30 minutes.
*2 “HLG (Hybrid Log Gamma)” is an international standard (ITU-R BT.2100) HDR format.
*3 “HSP” is an HDR picture format using HLG format video technology.
*4 6K PHOTO’ is a high speed burst shooting function that cuts a still image out of a 4:3 or 3:2 video footage with approx.18-megapixel (approx. 6000 x 3000 effective pixel count) that the 6K image manages.
High image quality even in low light situations with Dual I.S. to suppress blurring
The LUMIX S5 boasts a wide dynamic range and reproduces sharp images with exceptional clarity. Noise is minimised even when shooting at maximum ISO 51200 high sensitivity, making it an ideal camera to use in low-light situations.
The LUMIX S5 features Dual Native ISO sensitivity, a technology that was first introduced in the Panasonic professional cinema camera VariCam line-up. Normally, noise increases as sensitivity rises with a single native ISO image sensor. However, the image sensor with Dual Native ISO in the S5 minimises noise generation by choosing an optimal circuit to use according to the sensitivity before gain processing. As a result, it allows a maximum of ISO 51200 high sensitivity recording. Dual Native ISO gives film creators a greater variety of artistic choices as well as the ability to use less light on set, saving time. The LUMIX S5’s Dual Native ISOs are 640 and 4000.*1
Taking full advantage of its high-resolution sensor, the LUMIX S5 provides a high-resolution mode that faithfully reproduces precise details to be saved as beautiful, highly realistic images not only in RAW but also in JPEG. Eight consecutive images are automatically shot while shifting the sensor using the Body I.S. (Image Stabiliser) mechanism and synthesised into a 96-megapixel equivalent (12,000 x 8,000-pixel) image by the Venus Engine, which boasts high-speed signal processing.
The LUMIX S5 integrates the Body I.S. for powerful handshake correction. Panasonic has developed an algorithm that precisely calculates shake information acquired not only from the gyro sensor, but also from the image sensor and accelerometer sensor. This enables more accurate shake detection and compensation, making it possible to use a 5-stop slower shutter speed*2. Combining the Body I.S. (5-axis) in the camera and the O.I.S. (Optical Image Stabiliser, 2-axis) in the LUMIX S Series lens the 5-axis Dual I.S.2 compensates for blurring, allowing the use of a 6.5-stop slower shutter speed*3.
It is highly beneficial in telephoto shots and in adverse situations, such as in low-light or one-handed shooting. The 5-axis Dual I.S.2 works for both photo and video recording, including 4K. The Body I.S. compensates for camera movement even when other L-Mount lenses without O.I.S. are used.
With the Live View Composite function, the camera releases the shutter at designated intervals of exposure time and synthesises the parts with high luminosity to produce a single picture. While the total brightness of each consecutive image is accumulated in bulb shooting, only the target subject and the bright parts of an image are detected and the user can synthesize them carefully while seeing it in live view. This is useful for capturing shots of fireworks or stars in the night sky where the background needs no gain-increase.
*1 When recording mode is set to V-Log. The sensitivity varies depending on the recording mode.
*2 Based on the CIPA standard [Yaw/Pitch direction: focusing distance f=60mm when S-R2060 is used.
*3 Based on the CIPA standard [Yaw/Pitch direction: focusing distance f=200mm when S-E70200 is used. Firmware must be updated to the latest version.
High-speed, high-precision AF achieved supported by real-time detection technology
The LUMIX S5 possesses improved high-speed, high-precision AF in both photo shooting and video recording. Combining the Contrast AF with DFD (Depth From Defocus) technology, it focuses on the target in approximately 0.08 sec*1. As a camera that excels in low-light shooting, the LUMIX S5 boasts -6EV*2 luminance detection performance with Low Light AF thanks to the higher sensitivity and optimised tuning of the sensor. With 480 fps max communication speed between the sensor and the lens, users can take full advantage of this high-speed, high-precision AF when a LUMIX S Series lens is used.
The LUMIX S5 also incorporates advanced deep learning technology that detects specific subjects - humans and fast-moving animals, including dogs, cats and birds. Notably for humans, in addition to the eyes, face, and body, the head is also separately recognised by real-time detection technology to provide even more precise focusing. The camera keeps tracking the subject even if they move quickly, turn their back to the camera, tilt their head or move far away. In addition, improvements to DFD technology have enhanced AFC, which enables users to keep tracking small or fast-moving subjects to capture them in crisp focus whenever the shutter is released.
*1 11EV, at wide-end with S-R24105 (CIPA) in LVF120 fps setting
*2 At ISO100, F1.4, AFS
Reliable and flexible for optimum creative freedom
The compact LUMIX S5 boasts outstanding mobility while still achieving exceptional performance. To withstand heavy field use, the LUMIX S5 is composed of a magnesium alloy full die-cast body and is splash/dust-resistant*1. With an optimum layout of heat dispersion components, heat is effectively transferred outside which results in stable, continuous video recording for long periods.
The LUMIX S5 has a large LVF (Live View Finder) with a high magnification ratio of approx. 0.74x, as well as a high-precision, high-speed OLED (Organic Light-Emitting Diode) display which features a 2,360K-dot high resolution. Adoption of OLED for the LVF achieves high speed response with minimum time lag of less than 0.005 sec. With an eyepoint of approximately 20 mm, it offers high visibility with comfort for users wearing glasses.
A 3.0-inch free-angle LCD in 3:2 aspect with 1,840K-dot high resolution provides touch control. Composition during recording in various popular aspect ratios such as 16:9, 4:3, 1:1, 4:5, 5:4 and 9:16 can be checked with the Frame Marker function. A REC Frame Indicator identifies whether the camera is recording or not.
The LUMIX S5 has a double SD Memory Card slot - one slot complies with UHS-I and the other with the high-speed, high-capacity UHS-II (Video Class 90).
The camera’s battery can be recharged either via AC or USB according to the user’s convenience.
Compatibility with Bluetooth 4.2 (called BLE: Bluetooth Low Energy) enables constant connection with a smartphone/tablet with minimum power consumption. The settings of a LUMIX S5 camera can also be copied and transmitted wirelessly to other S5 cameras when using multiple S5 camera. Also, Wi-Fi 5-GHz (IEEE802.11ac)*2 is effective in addition to 2.4-GHz (IEEE802.11b/g/n.) This provides secure and stable connection on location for smooth remote control and high-speed data transfer.
*1 Dust and Splash Resistant does not guarantee that damage will not occur if this lens is subjected to direct contact with dust and water.
*2 5GHz Wi-Fi is not available in some countries.
LUMIX S5 – Introduction
The Panasonic LUMIX S5 is available for hire across the UK, with nationwide next working day delivery, HERE.
